Hardware
Material Jetting to new heights.
Our machine portfolio is built on the proprietary Micro Particle Jetting (MPJ™) technology and sets new standards in the additive manufacturing of high-performance technical ceramics. Every system we develop is consistently designed for maximum print quality, material versatility, and industrial scalability.
LAB II – A new dimension in ceramic additive manufacturing technology
The LAB II system is our answer to the growing demand of modern industrial applications. With precise control of printing parameters and the ability to process water-based suspensions, it enables the cost-effective production of complex components made from materials such as aluminum oxide (Al₂O₃) and sintered silicon carbide (SSiC).
Your Benefits at a Glance:
- Processing of technical ceramics using water-based suspensions – sustainable and efficient
- Scalable production platform for both prototyping and series manufacturing
- Optimized for demanding geometries and structural components
Our systems are engineered to redefine the limits of function, form, and fabrication.
SPECS
| Build volume (x | y | z) | 400x480x160 mm³ |
| Materials | Particle size up to 62 µm (D99) |
| Software | Proprietary User Software of D3 |
| Typical resolution vertical | 0,15 mm |
| Native printing resolution horizontal | > 300 X 300 dpi |
Currently Used Materials
Al₂O₃
Alumina (Aluminum Oxide, Al₂O₃) is the most widely used technical ceramic. It combines excellent electrical insulation, hardness, wear and corrosion resistance, and high temperature stability – making it ideal for demanding industrial and technical applications.
Key Properties
- Electrically insulating with high dielectric strength
- Very hard and wear resistant
- Resistant to heat and corrosion
Typical Applications
- Electrical insulators and substrates
- Wire and thread guides
- Thermocouple protection tubes
- Pump and valve components
SSiC
Sintered Silicon Carbide (SSiC) is one of the hardest and most advanced technical ceramics. It combines exceptional hardness, wear resistance, and high-temperature stability with outstanding chemical resistance. This makes SiC the material of choice for demanding applications where other materials reach their limits.
Key Properties
- Extremely high hardness and wear resistance
- High thermal stability (well above 1,600 °C)
- Excellent chemical and corrosion resistance
- Low density with high strength
- Good thermal conductivity and thermal shock resistance
Typical Applications
- Sealing rings, bearings, and pump components
- Nozzles, valves, and heat exchanger parts
- Mechanical components in abrasive environments
- Structural parts in high-temperature processes
- Components for energy, semiconductor, and aerospace industries
Software
Discover our software portfolio
D3 User Software
- Seamless workflow – voxel by voxel, drop by drop
- Automatic slicing and support generation
- Let the software do the work: it automatically sets all printing parameters based on the material identified by RFID – ensuring perfect results every time
- Monitor every printing process in real time and control all your print jobs through one intuitive interface
- Guided maintenance: interactive wizards ensure every maintenance step is carried out safely and with confidence – safe, simple, reliable
Manage multiple materials with D3 Material Manager
